DL-A 10-165/T-EN54 SKD

4 260590 184061

Surface-mounted ceiling speaker for Voice Alarm, power 10W, certified EN 54-24

Technical Data

Colour	RAL 9010
Dimensions	170x76 mm
Dispersion -6dB, 500Hz	h/v 360°
Dispersion -6dB, 1KHz	h/v 210°
Dispersion -6dB, 2KHz	h/v 95°
Dispersion -6dB, 4KHz	h/v 50°
Sensitivity EN54-24, 1W/1m	93,0 dB
Sensitivity EN54-24, 1W/4m	81,0 dB
Frequency Range	290 - 23.400 Hz
Frequency Response	230 - 24.000 Hz
SPL IEC268-5, 1W/1m	93,0 dB
SPL EN54-24, Pmax/4m	89,0 dB
Power	10/6/3/1,5 W

DL-A 10-165/T-EN54 SKD

4 260590 184061

Mounting Instruction

Mount the mounting plate on the wall or ceiling with the appropriate screws for the surface.
Insert the speaker cable through the cable entry of the mounting plate.
Connect the loudspeaker cable to the 100V and COM terminals.
If necessary, select a different power tapping.
Place the baffle on the mounting plate and fix it with the enclosed screws.

Please note: To avoid damage, we recommend loosening the cable lug with a flat-blade screwdriver when changing the cable to a different power tapping.
