WA 06-165/T Metal-EN54

4 260590 180544

Wall speaker for Voice Alarm, 6W power, certified EN 54-24

Technical Data

Colour	RAL 9010
Dimensions	252x192x81 mm
Dispersion -6dB, 500Hz	h=180° v=180°
Dispersion -6dB, 1KHz	h=160° v=160°
Dispersion -6dB, 2KHz	h=120° v=120°
Dispersion -6dB, 4KHz	h=76° v=76°
Sensitivity EN54-24, 1W/1m	94,0 dB
Sensitivity EN54-24, 1W/4m	82,0 dB
Frequency Range	170 - 18.500 Hz
Frequency Response	70 - 23.500 Hz
SPL IEC268-5, 1W/1m	94,0 dB
SPL EN54-24, Pmax/4m	90,0 dB
Power	6/3/1,5 W

WA 06-165/T Metal-EN54

4 260590 180544

Mounting Instruction

Attach the back panel of the speaker to the wall. Use the enclosed screws.
Feed the connection cable through the cut-out in the rear wall of the speaker or use the inputs on the side or top/bottom by knocking out the pre-punched holes and fitting them with the enclosed rubber grommets.
Connect the power cable to the ceramic terminal (COM and 100V). If necessary, select a different power tapping on the transformer.
Connect the red/black plug-in cable of the transformer to the loudspeaker.
Place the loudspeaker housing on the wall-mounted rear wall of the loudspeaker.
Use the 3 enclosed screws incl. spring washers to fasten the loudspeaker.

Please note: To avoid damage, we recommend loosening the cable lug with a flat-blade screwdriver when changing the cable to a different power tapping.
