EN54
TS-C 10-300/T-EN54
barcode 4 260590 180483

Sound column for Voice Alarm, 10W power, certified EN 54-24

Technical Data
Colour RAL 9006
Dimensions 285x100x92 mm
Dispersion -6dB, 500Hz h/v = 360°
Dispersion -6dB, 1KHz h = 187°, v = 108°
Dispersion -6dB, 2KHz h = 149°, v = 66°
Dispersion -6dB, 4KHz h = 91°, v = 32°
Sensitivity EN54-24, 1W/1m 89,2 dB
Sensitivity EN54-24, 1W/4m 77,2 dB
Frequency Range 210 - 17.700 Hz
Frequency Response 140 - 23.500 Hz
SPL IEC268-5, 1W/1m 89,0 dB
SPL EN54-24, Pmax/4m 88,6 dB
Power 10/6/3/1,5 W
EN54
TS-C 10-300/T-EN54
barcode 4 260590 180483
Mounting Instruction

Use a screwdriver for recessed head screws, Bit PH2.

  1. Mount the swivel bracket on the wall.
  2. Fit the sound column on the swivel bracket.
  3. Unscrew the base of the sound column.
  4. Insert the incoming cable through the cable gland and connect it to the terminal.
  5. Screw the base back onto the sound column.
Power Tappings
black brown red white green
COM 10 6 3 1,5
