EN54
MS 30-130/T black-EN54
barcode 4 260590 180643

2-way monitor speaker for Voice Alarm, 30W power, certified EN 54-24

Technical Data
Colour black
Dimensions 260x160x152 mm
Dispersion -6dB, 500Hz 360° (h) 360° (v)
Dispersion -6dB, 1KHz 200° (h) 160° (v)
Dispersion -6dB, 2KHz 130° (h) 100° (v)
Dispersion -6dB, 4KHz 120° (h) 40° (v)
Sensitivity EN54-24, 1W/1m 82,4 dB
Sensitivity EN54-24, 1W/4m 70,4 dB
Frequency Range 60 - 24.000 Hz
Frequency Response 50 - 25.000 Hz
SPL IEC268-5, 1W/1m 82,4 dB
SPL EN54-24, Pmax/4m 86,0 dB
Power 30/15/7,5/3,75 (8ohm) W
EN54
MS 30-130/T black-EN54
barcode 4 260590 180643
Mounting Instruction
  1. Mounting on the wall is done using the three parts of the enclosed swivel bracket. One for the wall (A), one for the speaker (B) and one connecting piece (C).
  2. Screw the mounting part (A) of the swivel bracket to the wall.
  3. Screw the second mounting part (B) to the speaker.
  4. Then join the two parts together via the connecting part and fasten with the enclosed screws (C).
  5. Connect the loudspeaker cable to the screw terminal. To do this, remove the strain relief from the enclosed touch guard.
  6. Place the terminal in the touch guard and lead the cable through the cable passage.
  7. Screw the strain relief back on. Close the touch guard.
  8. Plug the clamp onto the mating plug on the back of the speaker.
