WA 06-165/T-EN54V

4 260590 180537

Wall speaker for Voice Alarm, 6W power, certified EN 54-24

Technical Data

Colour	white
Dimensions	253x194x82 mm
Dispersion -6dB, 500Hz	h=180° v=180°
Dispersion -6dB, 1KHz	h=160° v=160°
Dispersion -6dB, 2KHz	h=125° v=125°
Dispersion -6dB, 4KHz	h=89° v=89°
Sensitivity EN54-24, 1W/1m	93,0 dB
Sensitivity EN54-24, 1W/4m	81,0 dB
Frequency Range	197 - 21.900 Hz
Frequency Response	175 - 23.500 Hz
SPL IEC268-5, 1W/1m	93,0 dB
SPL EN54-24, Pmax/4m	90,0 dB
Power	6/3/1,5 W

WA 06-165/T-EN54V

4 260590 180537

Mounting Instruction

Guide the connection cables through the cut-out in the rear panel of the speaker.
Attach the back panel of the speaker to the wall. Use the enclosed screws.
Connect the cable to the 100V transformer.
Place the loudspeaker housing on one side of the rear wall so that the clamping spring engages in the hole. Press the second clamping spring inwards with a screwdriver and at the same time press the speaker against the wall so that the second clamping spring engages
Use the enclosed plastic caps to cover the side holes.

Please note: To avoid damage, we recommend loosening the cable lug with a flat-blade screwdriver when changing the cable to a different power tapping.
