EN54
WA-AB 06-100/T-EN54V
barcode 4 260590 180568

Wall speaker for Voice Alarm, A/B-cabling, 2x6W power, certified EN 54-24

Technical Data
Colour white
Dimensions 252x194x82 mm
Dispersion -6dB, 500Hz single h/v 175° double h/v 180°
Dispersion -6dB, 1KHz single h/v 180°/160° double h/v 145°/130°
Dispersion -6dB, 2KHz single h/v 150°/135° double h/v 90°/80°
Dispersion -6dB, 4KHz single h/v 105°/90° double h/v 50°/40°
Sensitivity EN54-24, 1W/1m 91,6 dB
Sensitivity EN54-24, 1W/4m 79,6 dB
Frequency Range 227 - 14.600 Hz (single) 224 - 14.300 Hz (double)
Frequency Response 165 - 23.500 Hz (single) 162 - 23.500 Hz (double)
SPL IEC268-5 , 1W/1m 91,0 dB
SPL EN54-24, Pmax/4m 85,0 dB (single) 88,0 dB (double)
Power 2x 6/3/1,5 W
EN54
WA-AB 06-100/T-EN54V
barcode 4 260590 180568
Mounting Instruction
  1. Guide the connection cables through the cut-out in the rear panel of the speaker.
  2. Attach the back panel of the speaker to the wall. Use the enclosed screws.
  3. Connect the cable to the 100V-transformer.
  4. Place the loudspeaker housing on one side of the rear wall so that the clamping spring engages in the hole. Press the second clamping spring inwards with a screwdriver and at the same time press the speaker against the wall so that the second clamping spring engages
  5. Use the enclosed plastic caps to cover the side holes.
