EN54
DA-P 20-130/T-EN54
barcode 4 260590 180056

Sound projector for Voice Alarm, 20W power, certified EN 54-24

Technical Data
Colour white
Dimensions 137 x 222mm
Dispersion -6dB, 500Hz 360°
Dispersion -6dB, 1KHz 230°
Dispersion -6dB, 2KHz 110°
Dispersion -6dB, 4KHz 58°
Sensitivity EN54-24, 1W/1m 87,0 dB
Sensitivity EN54-24, 1W/4m 75,0 dB
Frequency Range 150 - 20.000 Hz
Frequency Response 120 - 21.000 Hz
SPL IEC268-5, 1W/1m 87,0 dB
SPL EN54-24, Pmax/4m 89,0 dB
Power 20/10/5/2,5 W
EN54
DA-P 20-130/T-EN54
barcode 4 260590 180056
Mounting Instruction
  1. Mount the U-bracket on the ceiling with the appropriate screws for the surface.
  2. If necessary, remove the speaker enclosure from the U-bracket.
  3. Mount the cable junction box on the wall or ceiling with screws suitable for the surface.
  4. Connect the loudspeaker cable to the terminals 100V and COM.
    If necessary, select a different power tapping.
  5. Close the cover of the junction box.
Power Tappings
black red yellow blue green
COM 20 10 5 2,5
