DL-E 10-165/T-EN54 safe
barcode 4 260590 180285

Ceiling speaker for Voice Alarm, power 10W, certified EN 54-24

Technical Data
Colour RAL 9016
Dimensions 199 x 73 mm
Ceiling Cut-out 166 mm
Dispersion -6dB, 500Hz V 180° H 180°
Dispersion -6dB, 1KHz V 180° H 180°
Dispersion -6dB, 2KHz V 145° H 145°
Dispersion -6dB, 4KHz V 72° H 72°
Sensitivity EN54-24, 1W/1m 87,3 dB
Sensitivity EN54-24, 1W/4m 75,3 dB
Frequency Range 232 - 11.900 Hz
Frequency Response 71 - 23.500 Hz
SPL IEC268-5, 1W/1m 87,0 dB
SPL EN54-24, Pmax/4m 85,0 dB
Power 10/5/2,5 W
EN54
DL-E 10-165/T-EN54 safe
barcode 4 260590 180285
Mounting Instruction
  1. Create the necessary ceiling cut-out and check the installation depth.
  2. Loosen the nut in the middle of the rear touch guard.
  3. Remove the touch guard of the speaker.
  4. Connect the loudspeaker cable to the terminals 100V and COM.
    If necessary, select a different power tapping.
  5. Put the touch guard back on the loudspeaker and secure it with the nut.
  6. Fold up the clamping spring and insert the loudspeaker into the ceiling cut-out.
  7. Press the speaker into the ceiling until it is flush with the ceiling cut-out.



Power Tappings
black red white green
COM 10 5 2,5
