EN54
WU-AB 06-100/T-EN54
barcode 4 260590 180575

Flush-mounted wall speaker for Voice Alarm, 2 x 6W power, certified EN 54-24

Technical Data
Colour RAL 9010
Dimensions 255 x 194,5 x 87 mm
Dispersion -6dB, 500Hz single h/v 180°/ 175° double h/v 180°/175°
Dispersion -6dB, 1KHz single h/v 160° double h/v 160°/150°
Dispersion -6dB, 2KHz single h/v 160°/150° double h/v 100°/75°
Dispersion -6dB, 4KHz single h/v 120°/60° double h/v 40°/35°
Sensitivity EN54-24, 1W/1m 89,0 dB (single) 92,0 dB (double)
Sensitivity EN54-24, 1W/4m 77,0 dB (single) 80,0 dB (double)
Frequency Range 126 - 12.300 Hz (single) 139 - 12.200 Hz (double)
Frequency Response 93 - 15.400 Hz (single) 106 - 15.400 Hz(double)
SPL IEC268-5, 1W/1m 89,0 dB (single) 92,0 dB (double)
SPL EN54-24, Pmax/4m 84,0 dB (single) 90,0 dB (double)
Power 2x6/3/1,5 W
EN54
WU-AB 06-100/T-EN54
barcode 4 260590 180575
Mounting Instruction
  1. Guide the connection cables into the installation housing.
  2. Place the installation housing in the wall recess.
  3. Connect the cables to the transformer.
  4. Insert the loudspeaker into the installation housing. Secure it with the enclosed screws.
  5. Place the grille on the speaker. Secure the grille with the enclosed screws.

Please note: To avoid damage, we recommend loosening the cable lug with a flat-blade screwdriver when changing the cable to a different power tapping.

Cable lug
