EN54
WU-SW 06-165/T Metal-EN54
barcode 4 260590 180599

Baffle speaker for Voice Alarm, 6W power, certified EN 54-24

Technical Data
Colour black
Dimensions 300 x 200 x 76 mm
Dispersion -6dB, 500Hz h=180° v=180°
Dispersion -6dB, 1KHz h=180° v=180°
Dispersion -6dB, 2KHz h=110° v=120°
Dispersion -6dB, 4KHz h=60° v=60°
Sensitivity EN54-24, 1W/1m 92,1 dB
Sensitivity EN54-24, 1W/4m 82,0 dB
Frequency Range 272 - 23.700 Hz
Frequency Response 106 - 23.500 Hz
SPL IEC268-5, 1W/1m 94,0 dB
SPL EN54-24, Pmax/4m 89,0 dB
Power 6/3/1,5 W
EN54
WU-SW 06-165/T Metal-EN54
barcode 4 260590 180599
Mounting Instruction
  1. Place the loudspeaker face down on the ceiling grid.
  2. Connect the speaker cable to the 4 pin screw terminal.
  3. Use a screwdriver to fix the connection of the cables to the screw terminal.
  4. Place the enclosed cable housing on the screw terminal to ensure permanent protection.
