EN54
DL-S 10-130/T plus-EN54
barcode 4 260590 180377

2-way ceiling speaker for Voice Alarm, 10W power, certified EN 54-24

Technical Data
Colour RAL 9016
Dimensions 216,5 x 141 mm
Ceiling Cut-out 186 mm
Dispersion -6dB, 500Hz h/v 180°
Dispersion -6dB, 1KHz h/v 180°
Dispersion -6dB, 2KHz h/v 110°
Dispersion -6dB, 4KHz h/v 72°
Sensitivity EN54-24, 1W/1m 87,8 dB
Sensitivity EN54-24, 1W/4m 75,8 dB
Frequency Range 104 - 22.700 Hz
Frequency Response 111 - 21.600 Hz
SPL IEC268-5, 1W/1m 87,0 dB
SPL EN54-24, Pmax/4m 88,0 dB
Power 10/5/2.5 (8) W
EN54
DL-S 10-130/T plus-EN54
barcode 4 260590 180377
Mounting Instruction
  1. Create the necessary ceiling cut-out and check the installation depth.
  2. Connect the connection cable to the screw terminal. Screw the wiring to the terminal with a screwdriver.
  3. Plug the terminal into the pin strip on the back of the speaker.
  4. Remove the strain relief from the enclosed contact protection cover. Place the terminal in the contact protection cover and lead the cable through the cable passage.
  5. Screw the strain relief back onto the cable passage. Close the touch guard.
  6. Insert the speaker into the ceiling until the speaker ring on the front touches the ceiling. Use the installation screw on the side of the speaker to fix it in the ceiling.
  7. The speaker grille can be used through magnetic fastening.
