EN54
DL-RQ 10-165/T plus-EN54
barcode 4 260590 180476

2-way ceiling speaker for Voice Alarm, 10W power, certified EN 54-24

Mechanical Data
Colour white
Dimensions 220x306x82 mm
Ceiling Cut-out 275 x 187 mm
Weight (net) 1,37 kg
Power 10/5/2,5 W
Connector 4-pin ceramic block
Mounting Screw system
EN54
DL-RQ 10-165/T plus-EN54
barcode 4 260590 180476
Mounting Instruction
  1. Use the enclosed mounting hook to remove the speaker grille.
  2. Loosen the wing screws of the plastic touch guard on the back of the speaker.
  3. Remove the contact protection and guide the incoming cable through the cable gland.
  4. Connect the incoming line to the terminal of the loudspeaker.
  5. Replace the touch guard on the back of the speaker and fasten it with the wing screws.
  6. Insert the speaker into the ceiling until the baffle touches the ceiling.
  7. Use the installation screws of the speaker to fix it in the ceiling.
  8. Place the grille on the speaker and gently press the grille on until it is firmly in place.
