EN54
DL 06-165/T-EN54W
barcode 4 260590 181268

Ceiling speaker for Voice Alarm, power 6W, certified EN 54-24

Technical Data
Colour RAL 9010
Dimensions 220x112 mm
Ceiling Cut-out 198 mm
Dispersion -6dB, 500Hz 180°
Dispersion -6dB, 1KHz 175°
Dispersion -6dB, 2KHz 100°
Dispersion -6dB, 4KHz 50°
Sensitivity EN54-24, 1W/4m 81,0 dB
Frequency Range 404 - 10.100 Hz
Frequency Response 80 - 24.000 Hz
Power 6/3/1,5 W
EN54
DL 06-165/T-EN54W
barcode 4 260590 181268
Mounting Instruction
  1. Create the necessary ceiling cut-out and check the installation depth.
  2. Fix the outer ring in the ceiling.
  3. Attach the fire dome to the ring in the ceiling.
  4. Lift the three springs on the spring slots on the ring, and turn them to the side. Guide the connection cable through the opening.
  5. Position the fire dome below the notches and then push it upwards. Turn the springs back into the spring slots (starting position).
  6. Connect the speaker cable with the WAGO terminals to 100V and COM: select the input with the corresponding power label according to the required power. Push the corresponding lever clamp upwards and insert the cable. Now lower the lever of the terminal again to fix the cable.
  7. Use the enclosed mounting hook to place the grille in the speaker ring and turn it clockwise.

Please note: Do not insert the hook into the grille more than 5mm from the outer ring to avoid damage. We recommend loosening the cable lug with a flat-blade screwdriver when changing the cable to a different power tapping.

Cable lug
