WA 06-77/T-EN54

4 260590 183743

Wall speaker for Voice Alarm, 6W power, certified EN 54-24

Technical Data

Colour	RAL9016
Dimensions	133x133x72 mm
Dispersion -6dB, 500Hz	h / v = 360°
Dispersion -6dB, 1KHz	h / v = 210°
Dispersion -6dB, 2KHz	h / v = 130°
Dispersion -6dB, 4KHz	h / v = 110°
Sensitivity EN54-24, 1W/4m	72,9 dB
Frequency Range	125 - 21.000 Hz
Frequency Response	112 - 24.000 Hz
SPL IEC268-5, 1W/1m	84,9 dB
SPL EN54-24, Pmax/4m	80,5 dB
Power	6/3/1,5 W

WA 06-77/T-EN54

4 260590 183743

Mounting Instruction

Mount the mounting plate/enclosure rear panel on the wall or ceiling using the screws suitable for the surface.
Insert the loudspeaker cable through the cable entry of the mounting plate/rear wall of the housing.
Connect the speaker cable to the 100V and COM terminals. If necessary, select a different power tapping.
Place the baffle on the mounting plate/rear panel of the enclosure and secure it with the enclosed screws.

Please note: To avoid damage, we recommend loosening the cable lug with a flat-blade screwdriver when changing the cable to a different power tapping.
