EN54
DL-SE 10-165/T-EN54
barcode 4 260590 183750

Ceiling speaker for Voice Alarm, 10W power, certified EN 54-24

Technical Data
Colour RAL 9016
Dimensions 220x104 mm
Ceiling Cut-out 188 mm
Dispersion -6dB, 500Hz 180°
Dispersion -6dB, 1KHz 175°
Dispersion -6dB, 2KHz 150°
Dispersion -6dB, 4KHz 94°
Sensitivity EN54-24, 1W/4m 81,4 dB
Frequency Range 63 - 16.000 Hz
Frequency Response 56 - 18.000 Hz
SPL IEC268-5, 1W/1m 92,0 dB
SPL EN54-24, Pmax/4m 89,0 dB
Power 10/5/2,5W
EN54
DL-SE 10-165/T-EN54
barcode 4 260590 183750
Mounting Instruction
  1. Create the necessary ceiling cut-out and check the installation depth.
  2. Loosen the screws of the terminal cover, slide it to the right and remove the cover.
  3. Guide the speaker cable through the cable gland of the terminal cover.
  4. Connect the speaker cables to the WAGO terminal.
  5. Put the terminal cover back on the rear of the speaker and slide the cover to the left. Tighten the screws again.
  6. Fold up the speaker's leg springs and insert the speaker into the ceiling cut-out until it is flush with the ceiling.
Power Tappings
black red white green
COM 10 5 2,5
