EN54
DL-BR 60-200/T plus-EN54
barcode 4 260590 183804

2-way ceiling speaker for Voice Alarm, 60W power, certified EN 54-24

Technical Data
Colour RAL 9016
Dimensions 319 x 254 mm
Ceiling Cut-out 302 mm
Dispersion -6dB, 500Hz h/v 180°
Dispersion -6dB, 1KHz h/v 165°
Dispersion -6dB, 2KHz h/v 130°
Dispersion -6dB, 4KHz h/v 80°
Sensitivity EN54-24, 1W/1m 91,2 dB
Sensitivity EN54-24, 1W/4m 79,2 dB
Frequency Range 63 - 22.200 Hz
Frequency Response 50 - 24.000 Hz
SPL IEC268-5, 1W/1m 93,1 dB
SPL EN54-24, Pmax/4m 94,9 dB
Power 60/30/15/7,5 (8) W
EN54
DL-BR 60-200/T plus-EN54
barcode 4 260590 183804
Mounting Instruction
  1. Create the necessary ceiling cut-out and check the installation depth.
  2. Open the metal cover on the back.
  3. Guide the connection cable through the rubber grommet of the metal cover.
  4. Connect the connection cables to the screw terminal. Screw the wiring to the terminal with a screwdriver.
  5. Plug the terminal into the pin strip on the back of the speaker. Screw the metal cover back on.
  6. Remove the grille with the enclosed mounting hook.
  7. Insert the speaker into the ceiling until the speaker ring on the front touches the ceiling. Use the installation screws on the side of the speaker to fix it in the ceiling.
  8. Replace the speaker grille
  9. To adjust the power, set the desired power using the rotary switch on the front of the speaker.
