EN54
DL-P 10-165/T SWF-EN54
barcode 4 260590 183941

Ceiling speaker for Voice Alarm, power 10W, certified EN 54-24

Technical Data
Colour RAL 9016
Dimensions 220x82 mm
Ceiling Cut-out 175 mm
Dispersion -6dB, 500Hz 165°
Dispersion -6dB, 1KHz 165°
Dispersion -6dB, 2KHz 145°
Dispersion -6dB, 4KHz 65°
Sensitivity EN54-24, 1W/4m 78,9 dB
Frequency Range 50 - 24.000 Hz
Frequency Response 42 - 25.000 Hz
SPL IEC268-5, 1W/1m 88,8 dB
SPL EN54-24, Pmax/4m 86,2 dB
Power 10/6/3/1,5 W
EN54
DL-P 10-165/T SWF-EN54
barcode 4 260590 183941
Mounting Instruction
  1. Create the necessary ceiling cut-out and check the installation depth.
  2. Insert the loudspeaker cable through the cable entry of the previously opened connector housing.
  3. Connect the loudspeaker cable to the terminals 100V and COM.
    If necessary, select a different power tapping.
  4. Close the housing again.
  5. Tension the springs upwards and insert the speaker into the ceiling cut-out with the springs first.
  6. Carefully relieve the tension on the springs until the speaker is centred in the ceiling cut-out.
Power Tappings
black red yellow blue green
COM 10 6 3 1,5
