EN54
DK 15/T-EN54-PG
barcode 4 260590 184849

Horn speaker for Voice Alarm, 15W power, certified EN 54-24

Technical Data
Colour RAL 7035
Dimensions 209x321 mm
Dispersion -6dB, 500Hz h/v 360°
Dispersion -6dB, 1KHz h/v 110°
Dispersion -6dB, 2KHz h/v 70°
Dispersion -6dB, 4KHz h/v 40°
Sensitivity EN54-24, 1W/1m 95,3 dB
Sensitivity EN54-24, 1W/4m 83,0 dB
Frequency Range 677 - 5.400 Hz
Frequency Response 300 - 13.800 Hz
SPL IEC268-5, 1W/1m 95,0 dB
SPL EN54-24, Pmax/4m 93,0 dB
Power 15/7,5/3,75/1,9 (20) W
EN54
DK 15/T-EN54-PG
barcode 4 260590 184849
Mounting Instruction
  1. Mount the U-bracket on the ceiling with the appropriate screws for the surface.
  2. If necessary, remove the speaker enclosure from the U-bracket.
  3. Insert the loudspeaker cable through the cable entry of the previously removed rear wall of the housing.
  4. Connect the loudspeaker cable to the terminals 100V and COM.
    If necessary, select a different power tapping.
  5. Carefully reinsert the back panel into the housing.
EQ Settings
EQ SETTING
Frequency
[Hz] 		Relative level to
1000 Hz for DK 10
[dB] 		EQ SETTING
Frequency
[Hz] 		Relative level to
1000 Hz for DK 10
[dB] 		EQ SETTING
Frequency
[Hz] 		Relative level to
1000 Hz for DK 10
[dB] 		EQ SETTING
Frequency
[Hz] 		Relative level to
1000 Hz for DK 10
[dB]
200800315+1212500
250100-12400+121600-4
31,50125-12500+820000
400160-8630+425000
5002000800-231500
630250+6100004000+8
800315+12125005000+12
100-12400+121600-46300+12
