EN54
DA-P 10-130/T-EN54-C
barcode 4 260590 180988

Sound projector for Voice Alarm, 10W power, certified EN 54-24

Technical Data
Colour RAL9016
Dimensions 137x 200 mm
Dispersion -6dB, 500Hz 360°
Dispersion -6dB, 1KHz 252°
Dispersion -6dB, 2KHz 110°
Dispersion -6dB, 4KHz 58°
Sensitivity EN54-24, 1W/4m 75,0 dB
Frequency Range 150 - 20.000 Hz
Frequency Response 120 - 21.000 Hz
SPL IEC268-5, 1W/1m 87,0 dB
SPL EN54-24, Pmax/4m 86,0 dB
Power 10/5/2,5/1,25 W
EN54
DA-P 10-130/T-EN54-C
barcode 4 260590 180988
Mounting Instruction
  1. Mount the U-bracket on the ceiling with the appropriate screws for the surface.
  2. If necessary, remove the speaker enclosure from the U-bracket.
  3. Mount the cable junction box on the wall or ceiling with screws suitable for the surface.
  4. Connect the loudspeaker cable to the terminals 100V and COM.
    If necessary, select a different power tapping.
  5. Close the cover of the junction box.
Power Tappings
black red yellow blue green
COM 10 5 2,5 1,25
