EN54
DA-SG 80-200/T plus white-EN54
barcode 4 260590 185921

2-Way outdoor speaker for Voice Alarm, 80W power, certified EN 54-24

Technical Data
Colour RAL 1013
Dimensions 380x443 mm
Dispersion -6dB, 500Hz h=360° v=360°
Dispersion -6dB, 1KHz h=360° v=235°
Dispersion -6dB, 2KHz h=360° v=230°
Dispersion -6dB, 4KHz h=75° v=135°
Sensitivity EN54-24, 1W/1m 86,0 dB
Sensitivity EN54-24, 1W/4m 73,3 dB (music) 68,0 dB (voice alarm)
Frequency Range 49 - 19.000 Hz (music) 70 - 20.000 Hz (voice alarm)
Frequency Response 40 - 24.000 Hz (music) 63 - 24.000 Hz (voice alarm)
SPL IEC268-5, 1W/1m 82,6 dB (music) 80,6 dB (voice alarm)
SPL EN54-24, Pmax/4m 92,9 dB (music) 88,0 dB (voice alarm)
Power 80/40/20/10 W
EN54
DA-SG 80-200/T plus white-EN54
barcode 4 260590 185921
Mounting Instruction
  1. Select a level and dry surface for your speakers.
    If you want to place the speaker on the surface, prepare suitable fixing material.
    If you want the speaker dug into the ground, prepare a sufficiently cast hole.
  2. Connect the speaker cable to the 100V and COM terminals before you place the speaker. Select a different power tapping and choose between music and voice alarm tuning at the rotary switches next to the speaker grille if necessary.
  3. Mount the speaker or dig it in.
