EN54
DL-S 15-100/T plus-EN54
barcode 4 260590 186096

2-way ceiling speaker for Voice Alarm, 15W power, certified EN 54-24

Technical Data
Colour RAL 9016
Dimensions 242x108 mm
Ceiling Cut-out 210 mm
Dispersion -6dB, 500Hz h/v 180°/180°
Dispersion -6dB, 1KHz h/v 175°/175°
Dispersion -6dB, 2KHz h/v 170°/160°
Dispersion -6dB, 4KHz h/v 100°/35°
Sensitivity EN54-24, 1W/1m 88,7 dB
Sensitivity EN54-24, 1W/4m 76,0 dB
Frequency Range 100 - 16.900 Hz
Frequency Response 90 - 17.000 Hz
SPL IEC268-5, 1W/1m 90,0 dB
SPL EN54-24, Pmax/4m 88,3 dB
Power 15/7.5/3.75 (8) W
EN54
DL-S 15-100/T plus-EN54
barcode 4 260590 186096
Mounting Instruction
  1. Create the necessary ceiling cut-out and check the installation depth.
  2. Remove the speaker grille, which is fixed by magnetic fastening.
  3. Guide the connection cable through the cable passage with the rubber grommet.
  4. Connect the speaker cable to the screw terminal at the front of the speaker. If necessary, use the rotary switch to select a different power adjustment.
  5. Plug the terminal into the pin strip on the front of the speaker.
  6. Attach a safety cable to the eyelet on the side of the speaker (not supplied).
  7. Insert the speaker into the ceiling until the speaker ring on the front touches the ceiling.
  8. Use the three installation screws on the side of the speaker to fix it in the ceiling.
  9. Reattach the speaker grille.
