EN54
WA-S 06-165/T-EN54
barcode 4 260590 185976

Wall-mounted speaker for Voice Alarm, 6W power, certified EN 54-24

Technical Data
Colour white
Dimensions 252x182x70 mm
Dispersion -6dB, 500Hz 180° 180°
Dispersion -6dB, 1KHz 160° 160°
Dispersion -6dB, 2KHz 125° 125°
Dispersion -6dB, 4KHz 89° 89°
Sensitivity EN54-24, 1W/1m 91,0 dB
Sensitivity EN54-24, 1W/4m 79,0 dB
Frequency Range 210 - 21.800 Hz
Frequency Response 184 - 23.300 Hz
SPL IEC268-5, 1W/1m 92,7 dB
SPL EN54-24, Pmax/4m 88,8 dB
Power 6/3 /1.5 W
EN54
WA-S 06-165/T-EN54
barcode 4 260590 185976
Mounting Instruction
  1. Remove the magnetically fixed grille with the enclosed mounting hook.
  2. Feed the speaker cable through the cable gland into the speaker housing.
  3. Connect the loudspeaker cable to the connection terminal of the loudspeaker.
  4. Fix the speaker to the wall in the desired orientation using the enclosed screws.
  5. The following alignment positions are available:

    • Horizontal alignment on the wall, the sound dispersion of the speaker is diagonally downwards.
    • Horizontal alignment between two walls and the ceiling, the sound dispersion of the speaker is also downwards (3 corner mount)
    • Vertical alignment in a corner between two walls (corner mount)

  6. Optionally, you can use two WA-S speakers to achieve bi-directional sound dispersion. To do this, mount one WA-S in vertical alignment, symmetrically mirrored to the second WA-S in vertical alignment.

    • Use the 12 target drilling points on the inside of the housing. Depending on the desired mounting position, drill through the 4 suitable drill points and insert the screws. Tighten the screws carefully.

  7. Put the loudspeaker grille back in place.
