EN54
DL-SE 06-165/T-EN54 safe STR
barcode 4 260590 186140

Ceiling speaker for voice alarm, 6W power, EN 54-24 certified

Technical Data
Colour RAL 9016
Dimensions 220x107 mm
Ceiling Cut-out 3,2 mm
Dispersion -6dB, 500Hz h/v 180°/180°
Dispersion -6dB, 1KHz h/v 175°/175°
Dispersion -6dB, 2KHz h/v 150°/150°
Dispersion -6dB, 4KHz h/v 90°/90°
Sensitivity EN54-24, 1W/1m 92,0 dB
Sensitivity EN54-24, 1W/4m 80,0 dB
Frequency Range 63 ~ 16000 Hz
Frequency Response 56 ~ 18000 Hz
SPL IEC268-5, 1W/1m 92,0 dB
SPL EN54-24, Pmax/4m 87,0 dB
Power 6/3/1,5 W
EN54
DL-SE 06-165/T-EN54 safe STR
barcode 4 260590 186140
Mounting Instruction
  1. Create the necessary ceiling cut-out and check the installation depth.
  2. Loosen the screws of the terminal cover, slide it to the right and remove the cover.
  3. Guide the speaker cable through the cable gland of the terminal cover.
  4. Connect the power cable to the ceramic terminal (COM and 100V).
  5. Connect the connection cable for the strobe light to the ceramic terminal (24V).
  6. Put the terminal cover back on the rear of the speaker and slide the cover to the left. Tighten the screws again.
  7. Fold the speaker's leaf springs upwards and insert the speaker into the ceiling cut-out until it is flush with the ceiling.
