EN54
WA-AB 06-100/T black-EN54
barcode 4 260590 186492

Wall speaker for Voice Alarm, A/B-cabling, 2x6W power, certified EN 54-24

Mechanical Data
Colour RAL 9005
Dimensions 254x195x81 mm
Weight (net) 2,09 kg
Power 2x 6/3/1,5 W
Connector 2-pin ceramic block
Terminal Diameter 3,2 mm
Maximum Cable Passage 8 mm² (single)
Mounting spring clamp
EN54
WA-AB 06-100/T black-EN54
barcode 4 260590 186492
Mounting Instruction
  1. Guide the connection cables through the cut-out in the rear panel of the speaker.
  2. Attach the back panel of the speaker to the wall. Use the enclosed screws.
  3. Connect the cable to the 100V transformer.
  4. Place the loudspeaker housing on one side of the rear wall so that the clamping spring engages in the hole. Press the second clamping spring inwards with a screwdriver and at the same time press the speaker against the wall so that the second clamping spring engages
  5. Use the enclosed plastic caps to cover the side holes.

Please note: To avoid damage, we recommend loosening the cable lug with a flat-blade screwdriver when changing the cable to a different power tapping.

Cable lug
